Everything about Shell and Tube type Heat Exchanger

Shell and Tube type Heat exchangers, are one of the most common types used onboard vessels and in general in industries like petrochemical industry and other industries with cooling requirements like HVAC where predominantly use of shell and tube type is considered economically viable.

Major advantages of shell and tube type includes easier manufacturing, low maintenance, easier fault finding and henceforth low downtime.

Materials knowledge:

Tubes are generally made up of Aluminum Brass (76% Cu, 22% Zn, and 2% Al). The Aluminum in this alloy is there to make a protective layer of AlO2. In case of corrosion, this ability makes Al more stronger rather than the case of Iron alloys. Also just to add, there is Zn anode also provided to save the whole system from corrosion.

Some coolers can also be found with 70/30 Cupro-Nickel.

What flows through tubes and what goes through the shell....?

Perhaps this question makes everyone scratch their heads. The common perseption would always lead to ask the question that what diffrence does it makes, its all about heat exchange which will always happen no matter the configuration. But there is significant changes which occurs in this.

So staying in the cooling configuration, the major objective is to  provide as much cooling to the concerned medium as possible. So, the cooling medium lets say Sea water remains in the shell outside the tubes and the other fluid lets say Lube oil stays inside the tubes. This has other implications too though, as flowing Sea water through the tubes might cause corrosion damage overtime and maintenace will be more often required. But, you get the idea right..!

Maintenenace:

1. Often problems like the leakages get introduced in system which is very necessary to be identified early. On ships, systems like LO system, is under constant supervision, where monthly tests, and parameters are observed regulary. As per my idea, temperatures and pressures around the cooler must be checked atleast 2x a day. Which gives you hint how system is performing over time.

For the operational POV working pressure is so adjusted such that prssure inside the tubes is always higher than the outside inside shell so the fluid inside is saved from any contamination. Generally the leaks are situated by the pressure testing or by the removing the pipework and end covers to expose the end plates, then looking again for signs of leakage. If possible, pressurise the other side of the cooler slightly, and look for leakage. Often you will find that one tube may be leaking, so this can be sealed up by making tapered brass plugs that can be hammered into the leaking tube to seal it off on both ends.

Repeat this process until the cooler can hold a pressure without leakage. With every tube that you plug, you reduce the cooling capacity of the unit, so don’t plug more than 25%, otherwise the cooler will not be effective any more. Sometimes you can also opt for replacing tubes with new tubes, so its virtually a new cooler after that.

Additional systems:

Tell-tale holes:

The tell tale hole as named, denotes the are for suspected leakages, helping to locate them early on and saving heavier plausible damage in future. Following is a general arrangement you can find in a shell & tube type Cooler.

Baffles:

Baffels are there to promote randomness and keep the cooling medium for a little more time in contact with the concerned fluid (Oil, Fresh water, etc. ). This in a way increases the efficiency of the heat transfer.

Floating tubesheet:

This is just there to accomodate for any changes in the length of the tubes, due to the temperature.

Freshwater Generation on ships

Ever wondered how the seafarer's get the freshwater onboard the ships? It intrigued me when I was about to join this career. Many of us have watched the movies where protagonist searches for drinking water and finds it empty. Well all my questions are now answered, after I studied about the Freshwater generation plant on board the vessels.

Freshwater Generator on ships works on a very basic principle. When we evaporate Sea water, it produces vapors, which can be cooled to produce distilled water. When added with required salts and minerals, it is fit for consumption. A typical freshwater must therefore contain an evaporator, a condenser, a mineralizer and a unit to check the consumption fitness of the produced water.

Before we go in depth study of the freshwater generator, lets be aware with the basic line diagram which will facilitate our learning.

Let's understand the whole working principle of the FWG system:

• Firstly the sea water is taken from the sea chest, and pumped through an ejector pump (explained later). The sea water in this state is at ambient sea water temperature which can be used as a cooling medium, thus, to increase the overall efficiency this sea water goes into the condenser unit of the Freshwater Generator. This causes the seawater to be in a preheated situation and also the water vapor coming from evaporator to cool down into distillate form.

• The hot sea water coming out from the condenser unit, is sent into the evaporator unit, and is also sent to the Air/Brine Ejector (Ejector pump) as the main working fluid. While sending it into the evaporator unit we pass it through the orifice plate which, fixes the feed rate of the sea water going into the FWG.

• Now the preheated sea water is in the Evaporator unit. We have to evaporate the sea water in order to produce the distillate, thus we need a heating medium. To increase overall efficiency the Main Engine Jacket Cooling water (JCW) system provides for the heating medium of the evaporator unit.

• Here one thing is very important to understand. The JCW system has freshwater at 80 degree Centigrade. To boil the sea water, we need either to elevate the temperature or decrease the boiling point. To decrease the boiling point we remove air from the unit using the Air/Brine Ejector. You can see a line coming from the top connected to the Ejector pump.

• Thus vacuum is created inside the Freshwater generator, which causes the sea water to boil at a reduced temperature of 80 degree centigrade. Now the vapors, go up through the Demister, and the left salty mixture (Brine) is settled in the bottom of the Evaporator unit. Demister ensures that no salts by any means go into the condenser unit from the evaporator unit to ensure so, it restricts the salt and only allows the vapor to go from evaporator to condenser.

• Now the vapor in the condenser exchanges heat with the sea water (as explained above), and the distilled water is formed in between the plates of the heat exchanger. The distillate is then taken out using a distillate pump which pumps out the distilled water prepared inside the generator. ***

• After this additional salts and minerals are added into the distillate to make it suitable for consumption in a Mineralizer. Following which the obtained freshwater is sent to the Freshwater Tank and is ready for consumption.

*** SALINOMETER

Salinometer is a device which keeps a check on the salinity levels of the distillate produced. The reading in the Salinometer is kept below 10 ppm. Usually the Salinometer is placed before mineralizer unit and after the distillate pump. As shown in the daigram:

Salinometer

Some Important Topics:

1. What is an Ejector Pump?
2. Why do we have a safety relief valve and a air purge valve at the top?
3. Do we have any Pressure or Temperature sensors on FWG? If so, why?

Let's answer them one by one.

Ans 1) Ejector pump basically works on the principle of Venturi effect. A high velocity fluid moving through a small cross sectional region, creates a vacuum which can be used to create a suction from a pipe attached in the same region. High velocity of working fluid creates an area of low pressure near the nozzle which creates a suction in the inlet region.

A simple Ejector Pump

Ans 2) The production of vapors and vacuum inside the FWG creates a region of variable pressure, which exposes a risk of rupture and crumbling under the pressure. A safety valve is necessary to remove excess pressure from inside of the FWG, similarly an air purging valve is use to fill the FWG with the air from atmosphere.

Ans 3) The FWG is also equipped with Pressure and Temperature sensing units, which continuously monitors the abnormal growth of pressure and temperature in the FWG unit.

HOW TO BATTLE SCALING IN FWG....?

One of the major problem in the FWG is formation of scales, which can minimize the heat transfer thus decreasing the overall efficiency of the system, and also result in less water production. Major scales forming compounds in FWG are:

• CaCO3
• Mg(OH)2
• CaSO4

To minimize the scale formation it is advised to run the FWG on its rated condition. Chemical treatment and regular inspection and maintenance reduces chances of Fouling and scaling inside the tubes in FWG.

I've tried to keep it short and cover all the topics in the blog. Please ask if I need to add anything....

Thank you for reading, Have a great day..!

ENTANGLED: GHOST GEAR

Ghost nets are the discarded nets in the ocean left accidentally or intentionally. The ghost gear includes the fishing nets, pots, traps, fishing lines, hooks and ropes. The problem lies in the fact that it is in a significant amount in the seabed. The problem with the ghost gear is that it not only lasts long since it is made from plastics, it also keeps doing its operation for which it was made, that is catching aquatic life.

Image source: Canadian Geographic

According to WAP (World Animals Protection) committee 1 lakh whales, dolphins, seals are stuck to death or injuries in these gears per year. The UN estimates that the discharge of this ghost gear is still increasing at an alarming rate of 640,000 tonnes per year, which is roughly around 1 ton per minute.

This heavy discharge ensures the fact that the 10 % of the total plastic waste in the ocean is the fishing gears lost or discharged. Loss to the marine environment can be estimated by the fact that in 2018  more than 300 turtles were killed stuck in the fishing gears in Mexico, the periphery of the USA.

Previous Symposiums

The issue is not new. Archives show that the first ever talk was done nearly 35 years ago in the 16th session of FAL in 1985. Till then, a lot of NGOs and local communities have taken their shoulders up for the change. The problem with the ghost gear is pretty simple to understand. The plastic content enables the gear to last long (approximately 600 years and then decomposing into microplastics) and also it continues to catch up the fishes and other aquatic life.

The cycle is pretty simple to understand. A small fish gets caught in the net attracting big fishes and thus a very huge fish ends up being caught in the ghost nets and ropes. Which gives them either death from suffocation or everlasting injuries. Gill nets are the worst in these scenarios. They are designed to catch the floating fish’s head or gill area. When left in the ocean this wall of drift net or gill net catches up the fish or turtles which either kills them by fatigue of dragging the net or extreme wound infections.

In 2019, extremely endangered species North Atlantic Right Whale was killed due to these nets and thus in the US and several other countries around the world have banned the production of these drift nets.

North Atlantic Right whale entangled in Ghost gear
Image courtesy: Radio Canada International

What needs to be done

Semi-Biodegradable and Bio friendly fishing gears:

This particular solution can not stop the nets from hunting the marine life but it can shorten the lifespan of the nets. The semi-biodegradable nets are basically composite materials and have some bio friendly polymers composition. The composition is some synthetic polymers polybutylene succinate (PBS) resin or polybutylene adipate-co-terephthalate (PBAT) resin. The semi biodegradable quality enables the economic feasibility of the fishing gears and thus helps in degradation of the fishing gears at the sea bed.

Providing Incentives:

One of the best ways is to provide the incentives to the fishing communities to bring back the damaged cables or nets and other items which are thrown overboard to amplify the Ghost fishing. Similar approaches have been applied in South Korea from 2003, the ghost nets are received and money is given hand to hand as per the weight of the ghost cable.

Image Source: Olive Ridley Project

Segregation and cleansing

Governments across the world must provide the maritime communities, some incentives weather in the form of money or any other goodies so as to create an awareness among the people associated with the maritime world like fishing communities and diving communities to collect those plastics which they find in the ocean. Nearly 2 to 3 years ago in a movie presented by oceanweek.eu presented the fact that fishing communities many a times encounter with the ghost gear and when approximated it comes to be in 60 to 40 ratio, later being plastic items. The fishers thus can be educated and provided those important incentives to bring back that 40%, as it also makes a change.

Another idea is to launch attractive programs as South Korea launched back in 2003 the “Derelict gear buyback program” or “Marine debris buyback program”  in which the government provided fishers the money in return of the ghost gear they provided. Similar programs can be launched for all kinds of marine plastic debris. Not only this, a separate program launched by NOAA allows the fishers to deposit their discarded ghost gear to the ports which accept them at no cost and thus facilitates the fishers to deposit that material which could be a pollution in upcoming years.

(Sources : The Hindu, Insider, The Dodo, National Geographic)

Machinery space bilge management

One of the most biggest challenge for a marine engineer is to manage the machinery space bilges on a vessel. This involves stringent regulations which needs to be followed to prevent the pollution from the oil. To understand the bilge management we should have a clear idea some basic questions which we will try to answer through this page:

• What is Bilge?
• What is Oily water separator?
• Use of Incinerator
• What are Bilge wells ?
• What is Bilge holding tank, how it is different from Bilge wells?
• What is sludge and how it is different from bilges?

Let's start with bilges. Machinery space has a number of oils involved at various places to serve in different manners. All these oils are used and circulated to account for the overall economic operation of the vessel. But, due to some leakages and discrepancies in the system, if the oil leaks from the lines and other designated places it comes down in tanks called as Bilge wells.

Usually the bilge wells are arranged in 4 corners of the machinery space. as given in the figure. This increases the chance of the leaked oil to end up in the bilge well. Naturally, the bilge wells are the most lowest tanks in the machinery space.

Also, the bilge doesn't only contains oil, a major portion is water, which also leaks from cooling systems and pipelines.

So the bottom line is, Bilge is the accumulated leaked water and oil, from the machinery space.

MACHINERY SPACE BILGE SYSTEM

Given below is a simplified version of the bilge system. Let's comprehend the full cycle.

Machinery Space Bilge Pipeline Layout
(Simplified)

• So the oil and water coming from the machinery space fills up the bilge wells. Whenever the bilge wells are fully filled up the high level bilge alarms glows which is a bad sign for a marine engineer specially when near a port since there are restrictions, as we can not pump the bilges directly overboard. Its a crime. So what do we do, when the bilge wells are topped up?

• We open the Bilge pumps, to pump out the bilges out of the wells, which goes into the Decanting tank. Decanting tank as the name suggests, separates the water and the oil, as oil floats over water and water stays in the bottom area. The water from the Decanting tank goes into the Bilge holding tank, whereas the oil is directly put into sludge tank.

• Bilge holding tank also contains water and oil as a mixture. The rules for the overboard discharge of bilge water is, The oil content in the bilge must be less than 15 ppm, to ensure which we have a oily water separator (OWS) in the vessels. The bilge water from the bilge holding tanks is treated in the oily water separator, which separates the water from the oil, and a mechanism to check the content of oil in the water coming out from OWS keeps a check that the water sent overboard has oil content less that 15 ppm. To understand working of OWS click here.

• The oil coming out from the OWS gets into the sludge tank. The sludge is a left over mixture of oil with a little water content. Sludge can't be burnt to produce enough power to propel the vessel or to provide power. Thus it is burnt in the incinerator and is smoke is discharged through the funnel.

In this manner the cycle is completed.

DISCHARGE REGULATIONS

The discharge of bilges directly into the oceans is prohibited, from the MARPOL Annexure 1. Following conditions must be met before discharging the bilge overboard.

• The ship is en-route. This means that ship is moving between established point A to another established point B. It can not discharge while moving in a non fixed voyage or while at anchorage or zero speed.

• The oily mixture is filtered through an oil filtering equipment as proposed in regulation 14 of the annex 1. Regulation 14 Annexure 1, puts an upper limit to the concentration of the oil in the bilge which is up to 15 ppm. That is the oil content should not be more than 15 ppm.

• The oil mixture should not be from or should not be mixed with cargo pump room bilges and oil cargo residues. That is, we can not mix the cargo p/p room bilges with the bilge from machinery space, also, the residual oil left in the oil tanker tank after tank cleaning can not be sent overboard through the machinery bilge system.

Other regulations are:

• The discharge from the vessel should not contain traces of chemicals or other substances in any quantities. Any chemical could result in environmental hazards.

• The oil residues which are prohibited to discharge must be kept onboard stored in a proper manner, which may be discharged at the port reception facility.

I have tried my best to keep it short and comprehensive at the same time. If you want something to add or if you have any questions, please comment below. Thank you for reading...!

COVID Resurgence: What Now....?

COVID-19 in its earlier waves was one of the biggest troublemakers in the industry and beyond. While it affected worldwide health, it also contributed to worldwide trade deficits. Now that COVID is back with its new strain in China and several other nations, it's high time that we must decide how to counter and fight this pandemic. Now is the time when rules must be laid, and additional care must be given so that these rules are not affecting the seafarers in their service and thus not constrain the world trade.

SEAFARERS Vs COVID: A WAR OF MANY TRADES

Seafarers are one of the most exposed working class if we talk about the pandemic. Various countries involved in the shipping means that each route is a combination of stringent regulations against the spread of COVID, which sometimes prohibits necessary affairs in the maritime industry like crew changes and shore leaves. As one of the most important working classes, seafarers have to battle these regulations laid by the nations.

There are some lessons we should take away from our previous experiences with COVID. As mentioned by IMO,

"At the height of the pandemic, some 400,000 seafarers were stranded on ships beyond the end of their original contracts and unable to be repatriated, due to COVID-related travel restrictions. A similar number of seafarers were stuck at home, unable to join ships and provide for their families".

To battle, this IMO previously created an entire team called by the name, Seafarer Crisis Action Team (SCAT), which worked in close conjunction with the International Labour Organisation (ILO), to help the seafarers who were stranded in international waters to reunite with their families. There are several case studies mentioned on the IMO's website in which IMO has laid several cases of such help and aid by the organisation.

Keeping a light on these events, it is obvious that we need an international free portal where immediate help can be sought by both the seafarers and their families. Additionally, the shipping companies may also provide some services and may take some necessary steps to ensure a balance for the seafarers. Plus, the international community should come together to discuss this on an international stage and come up with decisions which can be followed globally.

CONTAINER CONUNDRUM: WHAT CAN WE DO...?

Container stacking up on ports and ships making long voyages with empty containers just to ensure that the shipping industry is breathing is a situation which we have faced, which got escalated during the pandemic times. In an earlier post, we have seen How COVID choked the logistics industry. Go check it out, we can wait for sure...👀

There were times when over 20000 containers were sitting out in the international waters anchored in the ocean out of the ports for weeks. This not only delayed the logistics but also affected the mental health of the seafarers.

One of the reasons for this is, the absence of small vessels which can also be processed at the smaller ports. As the economy is thriving the shippers are shifting to heavier vessels which means only bigger ports can be used and small ports shrunk in business. This, of course, has catalysed this and COVID only made it worse. We definitely to talk about this too.

SAVING THE INDUSTRY IN THE PANDEMIC

We all need the shipping industry to be working and to be agile in these sensitive times. What we can do is simply provide the industry what it wants. There are certain changes required in the ways the industry works and we must get together in unison to provide it to the industry. Several maritime nations should come together and discuss viable choices and the regulations must be given some favours to the seafarers.

CYBER SUSCEPTIBILITY: The Cyber Vulnerability of Modern World

Hello there...

The dawn of the 21st century witnessed the introduction of new IT wonders and from there the human world hasn't turned its back. Every industry has seen the increased efficiency after the addition of  IT factor. The Maritime industry witnessed a digital revolution changing its entire form and making it more reliable after the digital revolution. The Digitalization of the world has pushed us in an entirely new era. An era where data is of the utmost importance and value.

Operating in a digital dimension has its own pros and cons. With ever-increasing digitization, the cyber attacks and world's vulnerability towards it, is also increasing hand in hand. Cybersecurity is currently one of the most discussed topic in the world. This time around, we are going to learn about the same.

CYBERSECURITY: WHAT & WHY

Cybersecurity can be understood easily as the entity protecting the entire corporate ecosystem from the outside world, given the excessive dependence of the corporate world is on the data and its management. Cybersecurity essentially checks the blocking and theft of any sensitive data which has the potential to strategically affect the business and performance of the company or organization.

In March 2021, The Italian Society for Cyber Security published the Clusit 2021 report, affirming the fact that 2020 was the worst year ever, in terms of the cyber attacks and most affected industry was the healthcare industry. The cyber attacks have increased by 12% when compared with the Clusit report 2020 encompassing the cyber attacks of 2019.

In nearly all the Clusit reports published over a period of 5 years by the Italian Society for Cyber Security, it has been observed that 80-90% of the accidents in the cybersecurity have a little contribution of human negligence. For instance let us take the example of Petya or NotPetya virus which struck the shipping giant Moller-Maersk and shook the whole maritime fraternity. The virus took computer systems as hostages to ransom money from the company. It has also attacked the companies like Saint Gobain, American Pharmaceutical company Merek sharp and Dome and Chernobyl Nuclear power plant in Ukraine.

Symbol of Petya Virus
Source: Wikipedia

This shows that there is a utmost requirement that the industry professionals and the employees must be aware of such attacks and how to cope up with them.

BASICS OF CYBER-SECURITY:

Before marching into the topic of cyber security, it is necessary for us to be well aware of the social engineering which is essentially the study of the psychological techniques of Human behavior. Using the ideas extracted from this social engineering, attackers attack and steal information through different possible methods.

There are a number of methods used for attacking any company or its employees. Some of them vastly used are mentioned here:

1. PHISHING

Phishing involves convincing people to provide sensitive information on the internet. Phishing social engineering the attackers exploit the people on there aspect of trust and Helping Nature and receive them for or extremely sensitive information like passwords and transaction information.

The activity is mainly done through emails and malware programs. An attachment sent through a mail can inject ransomware comma Malware and Trojan software air is a computer device so as to infect and does retrieved information. Whereas sometimes coma infectious links can also be sent by the scammers Who are disguised as company. Most of the times they are disguised as fake banks and merchandise websites.

2. SPEAR PHISHING

Spearfishing on the other hand is more organized. In this case attackers attack on specific target and gain access to the sensitive information about any organization, its intelligence, investor information and other significant data that can either be sold or be used to harm the business.

Spear phishing attackers mostly attack the mobile devices as these devices are more prone to 'clicking links and subscribing to things' ideology. After clicking the link and some password typing, a profile of the attacker is made on the device which gets access to all applications and personal information which can then be sent to the attacker.

3. WHALING

Really is quite similar to phishing and Spear phishing. Here the attackers attack on the high profile personal in the company to retrieve sensitive information and sometimes ransom as well.

4. SNIFFING

Sniffing is acquiring the data illegally while its transit from the sender to the receiver. The act of sniffing does not harms any computer system but it transfers the data which can be sensitive to the darker you can use it to harm the business of the company.

5. SPOOFING

Spoofing can be termed as cheat for theft. Cheating is a kind of activity which is as old as the human existence. In the act of spoofing a person claims to be an employee of a company but he or she is not. Similar can be in the case of website for applications as well. Any application or website can claim to be the official application or website for any mi company but in case of spoofing the application or website is a trap for the less aware people.

Spoofing can be done in following ways:

• Email Spoofing
• DNS Spoofing
• IP Spoofing
• DDoS Spoofing
• ARS Spoofing

ANALYSIS & MITIGATION

The mitigation of the cyber attacks is the proper education and implementation of Risk management program in the respective industry. A proper Risk management system determines the policies as rules and regulations to be followed so as to mitigate the risk of cyber attacks.

A Risk management program is calculated using 3 factors namely Threat, Vulnerability and Impact.

Threat is a potential cause of accident. It may include flood, fire, human unawareness and breakdown of the computer system. Whereas vulnerability encompasses the weakness of the management system. And the impact factor determines the actual damage caused in the cyber attack.

A cyber attack is usually done with an ambition which may include:

• To hamper the reputation and stature of the organization
• To use resources of organization
• To show off the hacking and attack skills
• Automated random attack through worm and viruses.

An attack simply affects the entire mechanism of the system and thus affects the entire business and working of the company. To protect such mishaps sensitive information in any company must be confidential, editable and available for the authorized personnel only.

THE RESPONSE OF IMO FOR CYBERSECURITY

International Maritime Organization, after acknowledging the threat of cyber security made it a necessity that the Security Management System (SMS) should adequately address. This was addressed to be done in the Security Management System by the first annual verification of the company's compliance document after the 1st January 2021 (Art 2).

IMO then published a document enlisting its guidelines on the maritime cyber risk management which consists of recommendation addressed to all the organization in Maritime sector to encourage the cyberspace security management practices and to safeguard shipments from cyber threats and vulnerabilities. IMO also identified the most vulnerable systems including:

• Information systems of Cargo
• Electronic Navigation
• Communication systems
• Information regarding the passengers (in cruises)

Not only IMO but also, associations like Baltic and International Maritime Council (BIMCO), Cruise Lines International Association (CLIA), International Chamber of Shipping (ICS), International Association of Dry Cargo Shipowners (INTERCARGO), International Association of Independent Tanker Owners (INTERTANKO), International Union of Marine Insurance (IUMI), Oil Companies International Marine Forum (OCIMF), published the document titled, 'The Guidelines on Cyber Security Onboard Ships'. This document mainly focuses to aware the industry professionals about:

• Identification of threats.
• Identification of vulnerabilities in the ship's information security system.
• Maritime cyber risk assessment.
• Detection of threat and minimizing its impact.
• Establishment of contingency plans to reduce the incidence of threats.

These recent developments shows the increasing awareness towards the Cyber risks in maritime industry. Now IMO identifies the Risk management as -

"The process of identifying, analyzing, accessing and communicating a cyber related risk and accepting, avoiding, transferring or mitigating it to an acceptable level considering costs and benefits of the actions taken to stakeholders."

CONCLUSION

The cyber based dimension is a good friend and a bad foe. On one hand it has provided us the non-limiting opportunities to learn and express. With a single mobile device, a person is connected to the world and its happenings. One can avail the world-class education sitting in an entirely different continent. On the other hand, it has also increased the scams and thefts and that too on an international levels. Overall, cyber-space is boon when used correctly and a curse for the world, when in the bad hands.

The world can only be aware and educated of the threats posed by the Cyber-attacks and its severity.

Hope that you enjoyed the article. Please mention your views in the comment section.

THANK YOU FOR YOUR VALUABLE TIME...

"Our best work is done, our greatest influence is exerted when we are without thought of self."

- Swami Vivekananda

A FUTURE LOST IN HISTORY: Saunders Roe Princess

Hi there!
It's been a while, I haven't posted anything new. But the topic which I am writing about, is so intriguing that I can say sorry for the delay. Please hold tight as we are going to read something magical.

THE GENESIS OF SEA-PLANES

The WW-II marked the important era of revolution in the manufacturing and development of the new industries, also counting the Airliner industry. But at that time there was a lack of airstrips and airports, which were (at that time) grass and dirt type. This fueled an option of seaplanes.

Source: Wikipedia

The starting was normal, some small planes and some with designs on the table. In 1943, one such design was made, which had a formidable space to carry more than 100 passengers and can fly at a good speed of 545 km/h. But due to high time at the WW-II, the design was pushed into drawers as an under-priority thing.

Source: TravelUpdate

But after WW-II was over, that design was going to make history, or better said, to register a name in pages of aviation history.

THE HISTORY IN THE MAKING

The design was taken over by the British aviation company of that time Saunders-Roe. They successfully constructed the model and launched it. The model had a 2-level cabin that could accommodate over 100 passengers and can fly at speed over 600 km/h. The plane was capable to fly at a height of 39000 ft. and was able to traverse a journey of 9000 km. At that time it was a wonder. The wonder had a name, as royal as its qualities were, the Saunders-Roe Princess.

Source: Historic Wings

Princess, had restaurants, resting lounges, personal bedrooms, and common rooms for the 100+ passengers, accommodated in the plane. The facilities were sound, giving an experience of life to all the passengers. It was equipped with the new technologies of that time, like Turbo-prop engines. The Saunders-Roe Princess had 8 counter-rotating turboprop engines, and 2 single propeller engines for a backup.

The expectation of the company, Saunders-Roe was too high for the seaplanes. They even proposed a similar approach for fighting jets, which could land on the water safely. And also advertised the Princess in almost every corner of the world. For the next few years, Saunders-Roe Princess was the center of attraction, in all the air shows.

THE REJECTION AND AFTERMATH

The year 1952 marked the dawn of the Jet airliners. Companies started booming in manufacturing and competition. The Saunders Roe Princess, was also racing for recognition and world scale advertisements.

The companies never showed their interest to the Saunders Roe Princess, rather they showed their belief in the Jet liners manufactured in US. The BOAC the biggest airliner company at that time in the United Kingdom, also showed no interest in the Sa-Ro Princess.

After the WW-II ended a lot was changed. The airstrips were now very common all across the world. The flying objects mainly used were land based planes like Boeing B-17 bombers.

A B-17 Bomber
Source: Wikipedia

The abundance of airstrips were not the only reason. There were some economic reasons too.

THE REASONS OF FAILURE

The Sa-Ro Princess was a giant. Since it had to take off from water, the power needed for takeoff was much more than that of land based Jet planes. Apart from this the hydrodynamic fuselage was also a reason. The hull of the Sa-Ro Princess was provided with pressure control systems which needed maintenance from time to time. Also the body of the plane required regular outer maintenance, as it spent some of its time in saline water.

Although the company tried for advertisements but, future never arrived for this future plane and eventually it was placed in the garages of Saunders Roe, in UK for long term storage. The engineers of Sa-Ro Princess, believed in another way. They thought that Sa-Ro Princess had not to compete against the Jet airliners, instead Sa-Ro Princess could easily outplay the ocean liners at that time. The company made another superior model by the name of Saunders Roe Queen.

The Sa-Ro Queen
Source: Wikimedia commons

Sa-Ro Queen, was undoubtedly a giant planned to compete with the Ocean liners of that time. A football field long 5 deck plan having a capacity to accommodate 1000+ Passengers, with 47 crew. The giant was planned to have 24 Jet engines, 12 on each sides. But this giant never came out of the table. This was due to its economic feasibility. An cruise liner is much more economic than a flying giant with a 24 jet engines. Even Saunders Roe had no way to start the construction of that, due to shortage of money.

THE FATE OF SAUNDERS ROE

Source: Wikipedia

Sa-Ro Princess was undoubtedly a good start for the company with a special ambition. But the failure of the company to convince the world market, pushed it to gradually change its way of approach. It merged with Westland Aircraft, and started its engineering in Hovercrafts and helicopters. Finally in 1964, it ceased all the operations.

Sa-Ro Princess after the rejection, several times was thought as an option for cargo transfer and even for nuclear powered operations. But, this never happened in the real space. The flying boat was eventually scrapped and sold.

THE CONCLUSION

The period of WW-II, was a period when a lot of innovational ideas were fueled. Some were successful, some were a failure. But all had one in common. It forces us to think, how the last 70 years have changed? Instead of fueling innovation we are stuck in the comfortable living.

"Be willing to step outside your comfortable zone once in a while, take the risk in life that seem worth taking."

- Sir Edward Whitacre Jr

RESURGENCE OF PIRACY: THE SOMALIAN PIRATES

Hello There!

With the advent of trade and commerce in the world, there has been a rise in several other activities hampering trade and commerce. Piracy is one of them. Generally, when we hear the word pirate, we think of a personality with hook-hand and eye-patch but the modern-day pirates are much more developed and technology supported. When researched one can easily say that the pirates have a total network of attackers, negotiators and local investors who fund them for the vital resources required for the pirate activities. Today we are going to learn about one of the most famous modern pirates of which many companies are afraid due to losses. We would learn every aspect and at the end comment what do you think about the same. Interested, let's dive in!

HISTORICAL ACCOUNT OF SOMALIA

Somalia was colonised by the British and Italian governments when they arrived in the horn of Africa region. In 1940 during World War II, Italian East Africa invaded the British Somalian region to gain control over the area. Eventually, British forces regrouped in Kenya and then again invaded the Somalian region. Consequently, the area was acquired by the British. After the formation of the UN, it gave the British government, total control over the British Somali region and at the same time Italy received trusteeship of the Italian Somali region. But it was mentioned that within 10 years Somalia would be independent. In 1960 after all the wars and changing governments, Somalia became an independent country. The government of Somalia was doing well until the president was shot dead in 1969. Following this, Mohammed Siad Barre, a military person formed the Somali Revolutionary Socialist Party (SRSP). This started the military rule in Somalia. The following events also saw the rise of left ideology due to the interference of foreign left personnel like Nicola Chojesku, Romanian left leader.

SOMALIA ATTACKS ETHIOPIA

In 1977 Somalia under Barre, invaded Ethiopia. Many powerful countries like the USSR and Cuba supported Ethiopia, resulting in the complete disband of SRSP in 1980. Following this, there were several new parties formed like SNM in northern Somalia, which also invited internal riots and eventually the Somalian Civil war in 1988.

Wikimedia commons

The political instability also resulted in chaos everywhere in Somalia and finally in 1991 the barre government was deposed. The northern Somalian region declared itself independent (although it is not accepted yet) and the southern region was war-stricken.

RISE OF PIRACY IN SOMALIA

Somalia lies in the Gulf of Aden region which is an important route for several fishes like Tuna. In the absence of any government, there were no Navy and coastal guard. This absence of administration invited a lot of foreign fishermen to catch fish illegally from the region and also big ships to dump harmful chemicals overboard. This caused huge economic drawbacks for the Somalian fishermen as the Fishes were killed by the chemicals. To revive their livelihood they opened their own association called Badaadinta badah which when translated in English is Saviours of the Sea. They started attacking the foreign fishermen to stop the illegal fishing in their region.

NRDC

In early 2000, they also realized that the Gulf of Aden is also one of the busiest routes for Cargo ships and Oil tankers. They found that huge international attention can be taken by boarding up these ships and taking them as a hostage to receive ransom from the shipping companies. This eventually turned the militia coast guards of Somalia into Pirates. The business of piracy, for these people, was much more profitable. Therefore many criminals and young people (mostly from Southern Somalia) also started earning profits from piracy.

INCREASING THE LIMITS

Le Figaro

The earned profits can be understood by the fact that when they boarded a ship in 2005 they received a ransom of $315,000. Which exponentially increased in the upcoming years. In 2007 they boarded and ransomed a ship for $1,500,000 and In 2011 a ship for $6,000,000. A study shows that the total ransom till 2009 was $58,000,000 which increased to $238,000,000 in 2010. Such a large sum of money for a War-torn, Famine-stricken country was not less than a boon. Every year many ships were now attacked and the crew was taken hostage and the ransom was asked to deliver. Soon the Somalian Pirates increased their range to 1000 kilometres from the Somalian coast as they saw the whole Indian Ocean as their battleground.

ATTACK METHODOLOGY

Usually, there is always a mother ship and two or three smaller ferry boats that are used to attack the huge cargo ships or oil tankers. For the Somalian Pirates, the cargo is not important they only take the crew as a hostage for ransom.

Seanews turkey

The funding and weapon arrangement is done by the local investors who buy a share and earn millions alongside these Pirates to facilitate this. There is also some debate over the Association of this pirate community with the Islamic Association of Al-Shabab, residing in the southern region of Somalia. One of the primary founders, with the increase of this Piracy the local fishermen of Somalia, are now facing peril. They are now driven out of the picture by the rich and powerful Somalian Pirates.

THE WORLD RESPONDS

2010 was the Heyday period for the Pirates, in which they earned a lot of money as ransom and also attacked every second ship for ransoms. But this also started the downfall of the Somalian piracy as several Naval Associations across the world, formed a task force specially designed for handling the Somalian Pirates.

Deccan Chronicle

There is also the construction of a naval base in North Somalia and also a Coast Guard at the Puntland. These steps essentially have lowered the speed of piracy considerably in the Somalian coastal region, but hasn’t yet stopped it. In 2013, the total piracy activities were decreased by 90% in total. But in recent years, it is again regaining international concern. In 2017, they held a crew hostage for ransom but soon released them. In 2020, they have attacked several ships (largely unsuccessful) for ransom.

The Task Force has to follow the Somalian laws and can not enter the coastal region thus when kept hostage it is really difficult to infiltrate and save the hostages. Also, the pirates caught can not be interrogated and executed anywhere. The caught pirates are safely taken by the naval boats to the Somalian coast. Therefore the total control can never be achieved over the Somalian pirates.

WHAT CAN BE DONE?

After looking into the total account of Somalia we can understand how badly the social, political and economic instability affects the nation. The steps taken by the companies and the naval organisations can have a check but can never stop this from happening. There is only one thing which can be done. Providing better education, better skillsets and most importantly employment to the youth of Somalia.

What we see in Somalia is just an outcome of what is going on there. The opposite can also be done all that we really require is basically better education, better professions and better central government. No weapons or threats can stop these pirate activities from happening, only the proper education and a strong central government can establish peace in the country of Somalia.

It is truly said by Nelson Mandela that -

"Education is the most powerful weapon which you can use to change the world..."

THANK YOU FOR READING !

THE ISLAND FROM THE PAST: North Sentinel Island

Hello there!

The North Sentinel island is located in the archipelago of Andaman and Nicobar Islands in the Bay of Bengal. The place has got its fame from the fact that the people here are still living in the Stone Age. Not far than 50 kilometres from the same place is the capital of Andaman and Nicobar Islands Port Blair, which is a developing city. It seems very interesting that under the range of 50 kilometres, there can be two places one being a major city and another being at a Stone Age. The same interest is the reason for the article today.

Vajiramias.com

The island is home to the Sentinelese tribe which moved from Africa to the North Sentinel Island nearly 60,000 years ago and were among the first African people to migrate from Africa. The fact that these people were among the first to migrate, is established upon the basis of two facts:

• Turtles are afraid of the island and don't visit there. It has been approved from studies that it takes 10s and 1000s of years for turtles to develop this awareness of hostility from a place. This supports the fact that North Sentinel island is the home to the tribe for a very long time.

worldwildlife.org

• During the British rule, the British administration tried to develop communication between Jarawa, Onge tribes and the Sentinelese tribe. They all had similar painting styles and had been there for years. But due to the long period of time elapsed the language gap was developed and both the languages of tribes had nothing in common. This also depicts that they have stayed there on the island for many years.

REMARKS AND VISITS TO THE ISLAND

The island has a lot of remarks from the past. In his own words, the 13th century Explorer Marco Polo said that “They are very cruel and kill and eat every foreigner whom they can land their hands upon.” There have been several attempts intended or accidental to establish contact with the Sentinel people. The first of the contacts include the 1867 shipwreck of Nineveh, an Indian Merchant ship that ran aground on Sentinel island and was attacked by the Sentinelese. They were eventually saved by the British patrol forces. Following this event in 1880, a British administrator, Morris Vidal Portman, brought 4 natives from the Sentinel island to the Andaman and Nicobar Islands to study end communication. Soon the elder ones (among the brought people), died due to the exposure to germs and pathogens. Fearful of this, Morris returned the children back to the island. And that was the last time one could do it because after that everything which approached the island was attacked from the Island. After a century passed, in 1977, a ship MV Presely, ran aground and just after four years in 1981 a freight and passenger ferry and operated by Transeuropa Ferries, MV Primrose Struck the island.

Fellowprimo

The crew members of both the Ships were eventually saved. Furthermore, Contacts include the visit of Belgian King leopard III in 1975, who was also attacked by one native resulting him, in fleeing away from the island.

FRIENDLY- INTERACTIONS

thetimes.co.uk

After all these events there has been a proper friendly encounter with the Sentinelese people. In 1991, the Indian government sent many anthropologists and researchers along with doctors and other enthusiasts to the island. They went alongside some people of the Onga tribe. They gifted several coconuts to the Sentinelese people. This was the only friendly interaction that has been done with the Sentinelese people.

THE 2004 TSUNAMI AND THE ISLAND

In 2004, A Tsunami broke out in the treacherous waters of the Indian Ocean. This tsunami caused a series of devastations in the Andaman and Nicobar Islands. A lot of cities were affected causing the loss of properties and assets. The Indian government sent helicopters and drones to the North Sentinel island, to review the conditions and the loss that happened at the Island. It was believed that the tsunami would have wiped out the Sentinelese people. When the helicopter reached above North Sentinel Island, it was attacked by arrows and sticks from the natives revealing the fact that they were alive and active.

Survival International

One of very intriguing discovery that was made in this 2004 helicopter visit came from the arrow which got stuck in the helicopter. the arrow was studied and it was found that The tips of the arrows were now made of iron rather than stone. This depicts the fact that the Sentinelese people have moved towards the Iron Age and have started using Iron as weapons. There was a good deep study and a fact was released that the ships MV Presely and MV Primrose have accidentally provided the Iron to the people which has started the Iron age at the Island. This is actually very interesting.

RECENT INTERACTIONS

Recent interactions have not been good and friendly with these Sentinelese people. In 2006, two drunk fishermen came nearer to Sentinel Island and were attacked and killed by the Sentinelese people. Their bodies were buried by the Sentinelese people which were retrieved by the Indian Government later. But this established the fact that these people are not cannibals.

The New York Times

Recently in 2018, an American missionary John Allen Chau was on an illegal mission to preach Christianity to the Sentinelese who got attacked and most probably killed by the Sentinelese people.

CAN WE GO THERE ?

The answer is very simple and straight forward, No we can’t. The Indian Government has banned all sort of visits and tours to the island. There are several reasons for the same:

•The hostile behaviour of the Sentinelese tribe. The past experience shows how much possessive they are towards any kind of visits. In these kinds of situations, it is better to just leave them alone.

•Disease. It is an established fact that when European went to America more than 90% of American natives were diseased and several were killed by the European germs and pathogens. Since these Sentinelese people haven't been in touch with the world for 10s and 1000s of years, they have not developed the immunity for the germs in the world. Consequently, any pathogen attack due to foreign interactions may result in a total wipeout of the community of Sentinelese people.

•Right to be alone. The Indian Government also have stated that if the Sentinelese people want to live differently and away from this modern world then they must be given the right to do so. For this Indian Naval forces patrol the area for any foreign activities that can disturb the inhabitants of the North Sentinel Island.

It is truly said that the world is full of amazing things. Nobody knows when and where we can spot or find anything. We are very rapidly moving towards a new era every day, and with the new era comes new responsibilities. One of them is taking care of these faraway places.

One must remember what Cheif Seattle said,

" The Earth doesn't belong to us. We belong to the Earth."

Thank you for reading !
